title: "Sungrow COM100D-EU Smart Kommunikationsbox (4G)"
description: "Sungrow COM100D-EU Smart Kommunikationsbox (4G) | Endast A-märken | Snabb leverans | Gratis frakt Grossist för Hållbara energiprodukter"

type: product_page

---

# Sungrow COM100D-EU Smart Kommunikationsbox (4G) - Art.No.: COM100D-EU

## Specifications

- **Märke**: Sungrow
- **HS-kod**: 90328900
- **Tillverkare**: Sungrow
- **Nettohöjd**: 315 MILLIMETER
- **Nettolängd**: 460 MILLIMETER
- **Nettovikt**: 4.9 KILOGRAM
- **Nettobredd**: 126 MILLIMETER
- **Ursprung**: Kina
- **Typ**: Övervakning

# **Sungrow COM100D-EU Smart Communication Box (4G)**


The Sungrow COM100D-EU is a robust smart communication box that simplifies the monitoring and management of PV installations. This box integrates the hardware and software functions of a Logger1000A-EU, ensuring a reliable connection between inverters, sensors, energy meters, and the iSolarCloud platform.


## **Key Features**


- Communication: Supports RS485, Ethernet, and wireless 4G communication via a micro-SIM card, as well as WiFi.
- Compatibility: The COM100D-EU can provide communication and monitoring for a wide range of Sungrow inverters, including models from the SGxxRT, SGxxRS, and SGxxCX series.
- Capacity: Can manage up to 30 devices via the 3 available RS485 ports.
- Connections: Equipped with 5 digital inputs and 4 analogue inputs for the integration of external sensors and measuring equipment.
- Power Supply: Operates on an AC input of 100-277 Vac, 50/60 Hz.
- Included: Logger1000A-EU, AC adapter, surge protection device (SPD), micro residual current device, and a night light for maintenance.


## **Benefits**


- Efficient Management: Enables batch firmware updates and parameter settings for inverters, optimising operational costs.
- Flexible Connectivity: Offers multiple communication options (RS485, Ethernet, 4G, WiFi), making the box suitable for various network environments.
- Comprehensive Monitoring: Supports the connection of various devices such as energy meters and weather sensors for detailed system surveillance.
- Reliability: IP66 protection and built-in surge protection for each communication terminal ensure safe and stable operation, both indoors and outdoors.
- Ease of Use: Local monitoring is possible, while the night light facilitates on-site maintenance.


## **Applications**


The Sungrow COM100D-EU is suitable for commercial and industrial PV projects but can also be used in larger residential installations where centralised management of multiple inverters and peripheral equipment is required. The robust housing allows for installation in both indoor and outdoor setups.


## **Warranty and Durability**


The communication box is designed for reliable operation in extreme conditions with an operating temperature range of -30 °C to 60 °C. The IP66 protection rating guarantees full protection against dust and powerful water jets, which extends durability and lifespan.

## Downloads

- [EN DS COM100D EU Datasheet V4 EN 20240725](https://cdn.estg.eu/p/6/7/6/1/67613e950d10895ae6a7c77c18567776f7cad7a2_EN_DS_COM100D_EU_Datasheet_V4_EN_20240725.pdf)
- [EN UM COM100D EU User Manual V14 202407](https://cdn.estg.eu/p/1/3/a/0/13a002d8b18f67a975c35e304482eed9c426d592_EN_UM_COM100D_EU_User_Manual_V14_202407.pdf)
